Axial flow pump — FAX

Features and benefits :

• API 610 design principles；

• Flanged casing with optional weld neck design；

• Oil lubricated antifriction bearings on smaller pumps with pivot shoe thrust bearing and integral cooler on larger pumps；

• Two-vane high efficiency propeller supported by extra heavy-duty shaft；

• Precision tolerances and clearances for reliable service；

• Hand polished propeller and elbow passageways；

• API610 seal chamber as standard with enhanced dimensions for special sealing systems；

• Dual or triple seals with API32+52 or 32+52+53 seal support systems；

• Spring mounted baseplate or optional mounting directly on reactor loop piping；

• Nozzle load capacity complies with API 610 design requirements；

• API610 materials with additional special materials to suit process specifications .
